WRe5 board:
Alloy composition: 5% rhenium, 95% tungsten
Density: ≥18.5 g/cm³
Melting point: ≥3050°C
High temperature resistance: excellent high temperature mechanical properties and thermal stability
Applications: aerospace, thermocouples, high temperature heating elements, etc.
WRe26 board:
Alloy composition: 26% rhenium, 74% tungsten
Density: ≥19.3 g/cm³
Melting point: ≥3050°C
High temperature resistance: excellent high temperature mechanical properties and thermal stability
Applications: aerospace, high temperature heating elements, high temperature measurement and control equipment, etc.
WRe41 board:
Alloy composition: 41% rhenium, 59% tungsten
Density: ≥19.7 g/cm³
Melting point: ≥3050°C
High temperature resistance: excellent high temperature mechanical properties and thermal stability
Applications: aerospace, high temperature heating elements, high temperature measurement and control equipment, etc.
Aerospace field: Because tungsten-rhenium alloy plate has excellent high-temperature performance and corrosion resistance, it is widely used in high-temperature components in the aerospace industry, such as engine nozzle liners, combustion chamber components, missile components, etc.
High-temperature heating elements: The high melting point and stability of tungsten-rhenium alloy plates make them ideal for high-temperature heating elements, such as those used in high-temperature furnaces, vacuum furnaces, and smelting equipment.
High temperature measurement and control equipment: Because tungsten-rhenium alloy plate has good electrical conductivity and high temperature stability, it is widely used in sensors, thermocouples and thermal resistors in high temperature measurement and control equipment.
X-ray targets: Tungsten-rhenium alloy plates are used as X-ray targets in the medical and industrial fields due to their high density and high melting point to produce high-energy X-ray radiation.
Electronic devices: Tungsten-rhenium alloy plates are often used as heat sinks, electrodes and conductive materials in high-power electronic devices due to their excellent thermal conductivity and electrical conductivity.
Laboratory application: Tungsten-rhenium alloy plates are also widely used in laboratories for high-temperature experiments, materials research and other scientific research fields.
